Bartakke’s Riveted Wall Mounting Boxes offer IP55 protection in a cost-effective, modular format. With a fully welded body and riveted top plate, this enclosure is ideal for indoor industrial applications requiring reliable access and ventilation. Finished in RAL 7035 powder coat for durability and clean aesthetics.
Select a standardised enclosure configuration to download an instant quotation.
SINGLE DOOR WMR BOXES 1.5mmTHK
| CATLOG NR. | WIDTH | DEPTH | HEIGHT |
| 300 | 210 | 300 | |
| 400 | 210 | 400 | |
| 500 | 210 | 500 | |
| 1151115 | 600 | 210 | 600 |
| 1151116 | 600 | 210 | 800 |
| 1151110 | 500 | 300 | 500 |
| 1151111 | 600 | 300 | 600 |
| 1151112 | 800 | 300 | 600 |
| 1151113 | 600 | 300 | 800 |
| 800 | 300 | 800 | |
| 1000 | 300 | 800 | |
| 1200 | 300 | 800 | |
| 1151117 | 400 | 350 | 600 |
| 1151118 | 600 | 350 | 400 |
| 1151119 | 600 | 350 | 600 |
| 1151120 | 600 | 350 | 800 |
SINGLE DOOR WMR BOXES 2.0mmTHK
| WIDTH | DEPTH | HEIGHT |
| 300 | 210 | 300 |
| 400 | 210 | 400 |
| 500 | 210 | 500 |
| 600 | 210 | 600 |
| 600 | 210 | 800 |
| 500 | 300 | 500 |
| 600 | 300 | 600 |
| 800 | 300 | 600 |
| 600 | 300 | 800 |
| 800 | 300 | 800 |
| 1000 | 300 | 800 |
| 1200 | 300 | 800 |
| 400 | 350 | 600 |
| 600 | 350 | 400 |
| 600 | 350 | 600 |
| 600 | 350 | 800 |
Parameter | Specification |
IP Class | IP55 (Complies with IEC 61439 & IEC 62208) |
Material | CRCA |
Surface Finish | Powder Coated |
Color | RAL 7035 Satin finish |
Design | Fully welded body with riveted top plate |
Mounting | Wall-mounted with integrated brackets |
Door Configuration | Single front door with front access |
Dimensions (mm) | Width: 300–600, Depth: 210–350, Height: up to 800 |
Accessories Included | Cable support bracket 22.5, 4” axial fan, 4” grill filter, tube light & limit switch brackets |
Product Type | Riveted Wall Mount Enclosure |
Target Tagline | “Economical Riveted Box” |
Plant Building
Durable and cost-efficient solution for indoor electrical setups.
Construction
Quick to install and adaptable for temporary or permanent needs.
Industrial Automation
Ideal for control panels in production environments.
OEM Applications
Reliable option for original equipment manufacturers focused on cost control.
Answer:
Riveted wall mounting boxes are protective enclosures used to store and safeguard electrical components, control panels, and other equipment. They are assembled using rivets, which makes them lightweight, strong, and easy to install on walls — perfect for places where space is limited.
Answer:
These boxes are commonly used in factories, workshops, commercial buildings, automation systems, and electrical installations. They provide a safe and organized place to mount and protect devices from dust, moisture, and accidental contact, especially in indoor or moderately protected environments.
Answer:
Here are some key benefits:
Lightweight & Durable: Strong enough for daily use but easy to handle and install.
Cost-Effective: More budget-friendly than welded enclosures.
Good Protection: Shields equipment from dust and water spray.
Space-Saving: Wall-mounted design keeps floor space free.
Easy Maintenance: Provides quick access for servicing components.
Answer:
Before buying, consider these points:
Size: Make sure there’s enough space for all your components.
Material: Choose one suited for your environment (mild steel, aluminum, etc.).
IP Rating: Check the level of dust and water protection needed.
Mounting Location: Ensure it’s suitable for the place you plan to install it.
Future Expansion: Consider leaving space for future upgrades.
Answer:
If you’re looking for reliable, durable, and well-designed riveted wall mounting boxes, Bartakke Enclosures is a trusted manufacturer. They offer high-quality enclosures built to protect your equipment, make installation easier, and ensure long-lasting performance for industrial and commercial applications.
